Features:
- Hand-forged from special tool steel
- Eccentric force action
- With gripping zone for flat and round material
- Integrated ring spanner (M8 13 M10)
- Nail holder at the tip of the pliers
- Induction-hardened cutting edge for hard and soft wires (H = 2.5 mm)
- Pliers with spring and closer
These pliers offer many advantages, especially for working on control cabinets or in switchgear construction. At the same time, they are as robust and versatile as the successful CombiMax combination pliers from NWS, combining their advantages with their own special ergonomic properties.
Special features:
Ergonomic grip position when holding and guiding objects
- Natural angled grip position in extension of the arm
- Gentle on hands, arms, and joints
- More freedom when working in tight spaces
- Significantly reduces workload when working overhead
- Non-slip grip and guidance with excellent freedom of movement
- Easier access to difficult, inaccessible areas
- No obstruction of vision when working at eye level, thus providing a better and clearer view during assembly work in control cabinets
- Clear view of the workpiece and material
- Controlled gripping of cables and wires
- 13 Accurate grip in all positions
- The slim shape also makes it suitable for wiring and cabling
- High and efficient cutting performance thanks to nws power industry
Technical details
Length in mm: 200
Length in inches: 8
Weight in kg: 0.285
Type: EC1
Cutting values
Soft wire = copper-aluminum-plastic: 5.9 mm
Hard wire = wire rope fiber steel wire: 2.5 mm
Multi-core cable: single and multi-core stranded: 13 mm
